CPU Support: Supports LGA1151 6/7/8/9th Gen Intel® Core i3/i5/i7/i9/ Pentium/ Celeron series processors
Chipset: Intel H110 Chipset
On-Board Graphics: Integrated Graphics Processor-Intel® HD Graphics support
Memory: DDR4 2133/2400/2666MHz (Max up to 64GB)
DIMM: 2 x Memory Slots
LAN: Onboard Realtek®100Mbit, 10/100 Mbit adaptive
Audio: HD Audio sound card chip, supports 6-channel output
SATA: 3 x SATA 3.0 port, 1 x M.2
Internal I/O:
1x USB 2.0 header supports additional 2 USB 2.0 ports •
1x USB 3.0 header supports additional 2 USB 3.0 ports •
1x Front Panel Audio header •
Expansion Slots: 1 x PCI Express x16 slot
Form Factor: Micro-ATX (19 x 17 cm)
OS Support: Support Windows 7 / 8 / 8.1 / 10(x64)
Mounting: 4 mounting holes
